OL4565FM Multiple Cutting Wire Cut EDM yog tsim los rau nruab nrab - loj conductive workpieces xav tau machining raug siab dua thiab txhim kho nto zoo los ntawm ntau yam - txiav ua. Nws nta 580 × 860 hli worktable, 450 × 650 mm X / Y mus ncig, 60 × 60 mm U / V mus ncig, thiab txhawb nqa workpieces txog li 500 mm tuab thiab 500 kg hauv qhov hnyav. Nrog ± 0.015 hli qhov tseeb qhov tseeb, ± 0.003 hli rov ua qhov tseeb qhov tseeb, qhov kev pom zoo ntawm machining raug ntawm ± 0.005 hli, thiab nto roughness mus rau 1.2 μm, OL4565FM yog tsim rau precision pwm, tooling, thiab xav tau hlau EDM txiav daim ntaub ntawv.
| Mechanical Specification | OL4565FM UAS | |
| Ua hauj lwm rooj loj | 580 * 860 hli | |
| X / Y axis taug kev | 450 * 650 hli | |
| U/V axis taug kev | 60 * 60 hli | |
| Z axis taug kev | 460 hli | |
| Max workpiece thickness | 500 hli | |
| Max. workpiece hnyav | 500 kg | |
| Tshuab lub cev hnyav | 1500 kg | |
| Tshuab lub cev pem teb cheeb tsam | 1720 × 1260 × 1700 hli | |
| Technical Parameter | ||
| Max. taper kaum / thickness | ± 6℃/ ± 15℃/ ± 30℃/ 80mm | |
| Max. machining ceev | 150 mm² / min | |
| Max. hlau pub tus nqi | 1 ~ 11.4m / sec (ntau zaus adjustable) | |
| Positioning raug | ± 0.015 hli | |
| Rov qab positoning raug | ± 0.003 hli | |
| Opitimal machining raug | ± 0.005 hli | |
| Opitimal nto roughness | 1.2μm | |
| Molybdenum hlau diam | 0.10 ~ 0.25 hli | |
| Fais fab mov | 3 theem / 380V / 50Hz | |
| Kev siv fais fab | 3kVA ua | |
| Standard Configuration | ||
| Kev sib txuas ntawm axis | XYUV axis simultaneous | |
| Qhia rail hom | Linear qhia | |
| XY axis tsav hom | Stepper lub cev muaj zog / servo lub cev muaj zog | |
| Central lubrication system | tsis siv neeg | |
| Dielectric tank peev xwm | 40 L | |
| Tus tswj | Vertical tswj txee | |
| Software platform | Qhov rai XP | |
| Tswj qhov system | Auto- txiav / Win- txiav / X8 / HL | |
| Lus qhia | Suav/English/Russian | |
| Saib xyuas | 17" LCD npo | |
| Digital readout zaub | XY axis DRO (5μm) | |
| CNC qhia | Standard ISO code | |
| Hom kis tau tus mob | USB/LAN | |
