OL5580FM Multiple Cutting Wire Cut EDM yog tsim los rau nruab nrab - mus rau - cov khoom siv hluav taws xob loj uas xav tau kev ua haujlwm siab dua thiab txhim kho nto tiav los ntawm ntau yam - txiav kev ua haujlwm. Nws nta 700 × 1040 mm worktable, 550 × 800 mm X / Y mus ncig, 60 × 60 mm U / V mus ncig, thiab txhawb nqa workpieces txog li 550 mm tuab thiab 800 kg hauv qhov hnyav. Nrog ± 0.015 hli qhov tseeb qhov tseeb, ± 0.003 hli rov ua qhov tseeb qhov tseeb, qhov kev ua haujlwm zoo tshaj plaws ntawm ± 0.005 hli, thiab qhov chaw roughness mus rau 1.2 μm, OL5580FM yog tsim rau precision pwm, cuab yeej, thiab siab dua - DMre kev siv.
| Mechanical Specification | OL 5580 FM UAS | |
| Ua hauj lwm rooj loj | 700 * 1040 hli | |
| X / Y axis taug kev | 550 * 800 hli | |
| U/V axis taug kev | 60 * 60 hli | |
| Z axis taug kev | 500 hli | |
| Max workpiece thickness | 550 hli | |
| Max. workpiece hnyav | 8 00kg | |
| Tshuab lub cev hnyav | 2100 kg ib | |
| Tshuab lub cev pem teb cheeb tsam | 1950 × 1550 × 2200mm | |
| Technical Parameter | ||
| Max. taper kaum / thickness | ± 6℃/ ± 15℃/ ± 30℃/ 80mm | |
| Max. machining ceev | 150 mm² / min | |
| Max. hlau pub tus nqi | 1 ~ 11.4m / sec (ntau zaus adjustable) | |
| Positioning raug | ± 0.015 hli | |
| Rov qab positoning raug | ± 0.003 hli | |
| Opitimal machining raug | ± 0.005 hli | |
| Opitimal nto roughness | 1.2μm | |
| Molybdenum hlau diam | 0.10 ~ 0.25 hli | |
| Fais fab mov | 3 theem / 380V / 50Hz | |
| Kev siv fais fab | 3kVA ua | |
| Standard Configuration | ||
| Kev sib txuas ntawm axis | XYUV axis simultaneous | |
| Qhia rail hom | Linear qhia | |
| XY axis tsav hom | Stepper lub cev muaj zog / servo lub cev muaj zog | |
| Central lubrication system | tsis siv neeg | |
| Dielectric tank peev xwm | 40 L | |
| Tus tswj | Vertical tswj txee | |
| Software platform | Qhov rai XP | |
| Tswj qhov system | Auto- txiav / Win- txiav / X8 / HL | |
| Lus qhia | Suav/English/Russian | |
| Saib xyuas | 17" LCD npo | |
| Digital readout zaub | XY axis DRO (5μm) | |
| CNC qhia | Standard ISO code | |
| Hom kis tau tus mob | USB/LAN | |
